SITECH and UPG double up to get council operations on grade

SITECH’s Dillon Harding and UPG’s Josh Weckert have teamed up to provide the total solution for a rural council.

The pair delivered and installed GCS900 Grade Control on a Wentworth Shire Council grader, a Cat® 140M, and also delivered on-site training.

“The council acquired an R10 GNSS and TSC7 controller from UPG several months before the purchase of the machine control equipment and employed it to assist the civil work among other purposes,” Josh said.

“UPG surveyed the vacant block and created a small road design for the grader and the off-machine equipment,” Dillon said.

“We spent the morning with the guys helping them come to grips with the total station and switching to machine control mode.”

“We also talked about grader best practices and general benching techniques then cut some passes with the machine.”

Josh had Trimble SiteVision running in the background so the council engineers could see the same road design that was in the machine, giving them a greater understanding of the solutions on offer.

“The reaction from the council team, especially SiteVision, was very positive,” Dillon said.

“SiteVision is a major a step forward and, among other advantages, is an amazing way to showcase jobs to projects managers and investors.”

The council is undertaking a section of road redevelopment soon as well as a proposed re-development of the Mildura Aerodrome, in which a tight tolerance is paramount.

“Council representatives came to our demo day in Adelaide last year and saw the live display of our solutions in hardware and software,” Dillon said.

“The decision was made from that experience to outfit the grader with the complete package so the council could do the aerodrome job itself rather than sub-contract it.”

You can find out more about SiteVision, Trimble’s outdoor augmented reality system, here.

To learn more about how Trimble and SITECH can help your operations reach new levels of accuracy, efficiency and safety, call us on 1800 748 324

Onsite training brings bespoke manual to life

(L-R) Jim Skelhorn, Jake Madden, Shaun Gray and Sean Madden hit the ground running....

Contact your local SITECH support rep for training information.....

While many of us were perhaps having a slow start to the new year, two SITECH trainers and a group of surveyors and grader operators hit the ground running with a two-day workshop in the Gold Coast Hinterland in Qld.

The sessions were held in January at a civil site at Upper Coomera for surveyors from Survey Management Solutions and operators with CCA Winslow.

The aim of the training was to refresh and revise the group’s skills and knowledge of both the SCS900 and GCS900 software packages from Trimble and how they work and interact with the Trimble Total Station.

At the basis of it all were new manuals created by SITECH product support representatives Shaun Gray and Jim Skelhorn which, as Shaun explained, were specifically created for SMS and CCA Winslow to make life easier for everyone.

“The manual contains all the info we know these guys need specifically for the work they do,” he said.

“Because it has been customised for them they now don’t have to wade through the whole manual looking for what they need.

“It means less downtime - and we are only able to do this because of the solid and long-term relationships SITECH has with the companies.”

Part of the training involved the surveyors getting to know GCS900 (which is aimed at the operators) and the operators with SCS900 (surveyor orientated) so that both groups understand how the other works, potentially leading to more seamless operations.

“An example of that would be the surveyors seeing how the info from SCS900 is handed over to the machines for machine guidance,” Shaun said.

“It gives them a greater appreciation of how the information they gather and create translates, in this case, into the actual operation of a grader.

“The sessions also gave the guys the chance to ask questions and to explore aspects of the software and hardware they perhaps hadn’t fully exploited before.

“Everyone involved has been using the system and software for some time, so the sessions were really about fine-tuning and sharing knowledge.”

SITECH undertakes such training on-site on a regular basis. If you would like further information on training available for your operation, contact your local SITECH rep to find out more.

Trimble GCS900 GCS receiver compatibility

In order to use an MS992 or MS990 Receiver with the newly released MS995 Receiver in a dual configuration on a dozer or grader, users must be running Trimble GCS900 Grade Control System version 13.10 or Cat® AccuGrade™ version 13.10.

Running previous versions of the grade control system in a mixed receiver configuration will result in incorrect system guidance. Upgrading to version 13.10 corrects this issue.

You are eligible to upgrade if you have a current Trimble Protected Firmware plan.
If you would like further information on this upgrades, or Trimble Protected, please contact your local SITECH office or call head office on 07 3851 8370.

Efficiency helps complete earthworks project early

georgiou-250x150When Georgiu Group, a national building construction, engineering and property development company, were awarded a land development project, they took this opportunity to review their productivity and cost control. The six-month project in Alkimos, Western Australia, involved moving 600,000 cubic meters of sand, rock and limestone 1.5 kilometers between the cut and fill zones. The site measured 2 kilometers long by approximately 600 meters wide. To get a better understanding of payloads, movement of material, and the productivity of operators and mass haul routes, Georgiou turned to SITECH WA.

In the past, Georgiou manually collected payload data to map to cost centres. They had no access to real-time data on productivity and material movement leading to potentially inaccurate and sometimes delayed information.

On this project, the team adopted a range of Trimble® solutions including: the 3D GCS900 Grade Control System, 2D Project Monitoring on Haul assets and LOADRITE X2350 excavator scales. Data from this hardware was used by InsightHQ and VisionLink® software to improve productivity, increase data transparency and accuracy, and therefore reduce costs. Georgiou used Business Center – Heavy Construction Edition (HCE) software for Mass Haul Analysis and Design Creation.

Georgiou saw benefits in the following areas

  • 33% project time reduction and 25% hauling productivity gain through transparency of payloads
  • Real-time visibility of cost to move material, load times, and other vital production data
  • Quickly-defined optimal haul zones using Business Center – HCE
  • Ability to monitor where material was removed and dropped
  • Improved productivity with access to accurate, automatic production and volume reports

Read the full story of how Georgiou used the Trimble technology to increase productivity and finish the project early on the Trimble website.
